| INPUT SPEC. | |
| Input Voltage Range | 90~264Vac |
| Input Frequency Range | 47~63Hz |
| Input Current | 1.7A@90Vac, max. load |
| Efficiency | 87% @115/230Vac typical load |
| | |
| OUTPUT SPEC. | |
| Output | Load | Range | Regulation | Rated Power | | Voltage | Min | Max. | (V) | Wattage | | 19V | 0A | 3.42A | 18.05V ~ 19.95V | 65W |
|
| Ripple Noise | Ripple with spike noise £ 350mVp-p |
| Hold-up Time | 5 ms min.@115Vac input, full load |
| Turn-on Delay | 5 sec. max.@115Vac |
| | |
| GENERAL SPEC. | |
| OVP | 29V max automatic shut down (latch model) |
| UVP | No damage when input voltage below min. at 90Vac/50Hz |
| SCP | Output can be shorted without damage, and auto recovery |
| OTP | No damage, no shut down (latch model) |
| OCP | Output current limit in 5.5A max. |
| Leakage Current | Should be less than 100uA |
| VDE | CISPR22 Class B |
| MTBF | 100Khrs min at 25°C at 110/220Vac |
| Weight | 220g |
| Dimensions | 47*107*29.3mm |
| | |
| ENVIRONMENTAL SPEC. | |
| Operating Temperature | 0 ~ 40°C |
| Storage Temperature | -31 ~ 60°C |
