Motherboard Form Factor Support

ATX / Micro-ATX / Mini-ITX

I/O Ports

2 x USB 3.2 Gen 1 Type-A

1 x Audio

1 x Mic

1 x LED On/Off button

1 x Reset button

Drive Mount Support

3 x 2.5"

2 x 2.5" / 3.5"

Expansion Slots

7

Maximum GPU Length

330 mm / 12.99 inches

Maximum CPU Cooler Height

160 mm / 6.29 inches

Power Supply Support

ATX

Maximum PSU Length

200 mm / 7.87 inches (without 2.5"/3.5" HDD tray installation)

Fan Size Support

Front: 3 x 120 mm / 2 x 140 mm

Top: 2 x 120 mm / 2 x 140 mm

Rear: 1 x 120 mm

PSU Shroud: 2 x 120 mm

Pre-installed Fan Size

Front: 3 x 120 mm

Top: 2 x 120 mm

Rear: 1 x 120 mm

Pre-installed Fan Type

Front: 3 x auto-RGB Fan

Top: 2 x auto-RGB Fan

Rear: 1 x auto-RGB Fan

Radiator Size Support

Front: 120 / 140 / 240 mm

Top: 120 / 240 mm

Rear: 120 mm

Dimensions (DxWxH)

411.6 x 210 x 498 mm / 16.20 x 8.26 x 19.60 inches

Net Weight

6kg / 13.23lbs

Gross Weight

6.96kg / 15.34lbs

Connection

LED On/Off Button

2 x USB 3.2 Gen 1 Type-A

Mic In

Audio Out

Reset Button

Power Button
